WDI7500 Industrial 2D Barcode Scanner w/USB cable

WDI7500 Industrial 2D Barcode Scanner w/USB cable overview

Manufacturer

Wasp Barcode Technologies

Manufacturer Part Number

633809002830

Brand Name

Wasp

Product Model

WDI7500

Product Name

WDI7500 Industrial 2D Barcode Scanner w/USB cable

Marketing Information

Wasp WDI7500 2D Barcode Scanner The Wasp WDI7500 industrial 2D barcode scanner is built for the harshest and most demanding applications in warehousing, transportation and logistics, and manufacturing industries. This 2D USB barcode scanner is a preferred corded scanner because of its omnidirectional reading capability which provides accurate scanning of both types of barcode, whether 1D or 2D barcodes from printed labels or mobile devices, regardless of the orientation, from contact to over 3.3 ft. depending on the barcode resolution. It also includes a four dot aiming system that provides quick and accurate scans to increase efficiency and ensure error free scanning, making it an ideal desktop barcode scanner or QR code scanner in decent ambient light. Innovative, rugged and ergonomic, the Wasp WDI7500 industrial 2D barcode scanner is designed to provide a comfortable data collection for the user and a reliable operation in the long term. This ultra-rugged scanner operates in a wide range of temperatures, has a water and particulate sealing rating of IP65 and maintain its reliability even when subjected to repeated 6.6 ft. drops on concrete if it's not plugged into a USB port. The Wasp WDI7500 industrial USB barcode scanner incorporates advanced features to excel in the most demanding environments: œLiquid lens� that adapts and focus at different distances; this provides a versatile optic that is able to fulfill any scanning need with a single corded scanner. It also features 3 Green Light technology for visual good-read feedback and loud beeper for audio good-read feedback. The WDI7500 industrial 2D barcode scanner includes a 2-year manufacturers warranty covering material defects. If you would like to upgrade this coverage, WaspProtect extended service plans cover accidental breakage and can provide coverage beyond the original warranty.

Product Type

Barcode Scanner

Technical Information

Connectivity Technology

Cable

Scanning Capability

Barcode Symbology Supported

GS1 DataBar linear codes
Aztec Code
China Han Xin Code
Data Matrix
MaxiCode
Micro QR Code
QR Code
Australian Post
China Post
IMB
Japanese Post
KIX Post
Planet Code
Portuguese Post
Postnet
Royal Mail Code (RM4SCC)
Swedish Post
EAN/JAN Composites
GS1 DataBar Composites
GS1 DataBar Expanded Stacked
GS1 DataBar Stacked
GS1 DataBar Stacked Omnidirectional
MacroPDF
MicroPDF417
PDF417
UPC A/E Composites

Light Source

LED

Image Sensor Type

Imager

Scan Mode

Trigger

Scan Pattern

Omni-directional

Scanning Distance

848.36 mm

Features

Ergonomic Design

Cable Type Included

USB

Reading Angle (Skew)

40°

Reading Angle (Pitch)

40°

Reading Angle (Roll)

360°

Maximum Ambient Light

100000 lux

Drop Specification

6.6 ft. (2.0 m)

Minimum Print Contrast

15%

Minimum Element Resolution (DataMatrix)

0.19 mm

Maximum Element Resolution (DataMatrix)

0.25 mm

Minimum Element Resolution (PDF417)

0.25 mm

Image Sensor Resolution

864 x 544

Illumination Type

LED

Illumination Color

White

Interfaces/Ports

Host Interface

USB

Power Description

Standby Current

180 mA

Environmental Conditions

Operating Temperature

-20°C to 50°C

Storage Temperature

-40°C to 70°C

Humidity (Non-condensing)

0% to 95%

Physical Characteristics

Form Factor

Handheld

Rugged

Yes

Color Family

Dual Colour

Product Color

Yellow

Durability

Dust Resistant

Weight (Approximate)

328.9 g

Miscellaneous

Ingress Protection (IP) Rating

IP65

Application/Usage

Entertainment
