1U, 10 x 2.5" Gen4 NVMe hot-swap, 1100W Redundant PSU
£2185.68 inc vat
£1821.40 ex vat
Or £94.42 for 24 monthswith 10% deposit of £218.57
| CPU Support | 5th Generation AMD EPYC Processors or 3rd Generation AMD EPYCProcessors AMD EPYC™ 7001/7002 Series Processors |
| Socket | 1 x Socket (LGA 4094) |
| Memory | Total Slots:16 Capacity :Maximum up to 128GB Memory Type :DDR4 |
| Expansion Slots | Total PCI-E Slots: Riser Card CRS101D: - 1 x PCIe x16 (Gen4 x16) FHHL slot 1 x OCP 2.0 mezzanine slot with PCIe Gen4 x16 bandwidth (Type1, P1, P2, P3, P4) - Occupied by CNVP143, 4 x NVMe HBA |
| Storage | 2 x M.2 slot: - M-key - PCIe Gen4 x4, x4 - Supports 2242/2260/2280/22110 cards |
| Storage Bays | 10 x 2.5" Gen4 NVMe hot-swappable bays |
| Networking | 2 x 1Gb/s LAN ports (1 x Intel® I350-AM2) Support NCSI function 1 x 10/100/1000 Mbps Management LAN |
| Graphics | Integrated in Aspeed® AST2500 - 1 x VGA port |
| I/O Ports | Front I/O 1 x USB 3.0 1 x Power button with LED 1 x ID button with LED 1 x NMI button 1 x Reset button 2 x LAN activity LEDs 1 x Storage activity LED 1 x System status LED Rear I/O: 3 x USB 3.0 1 x VGA 1 x COM 2 x RJ45 1 x MLAN 1 x ID button with LED |
| OS Support | Citrix Hypervisor 8.1.0 or later Red Hat Enterprise Linux 7.6 or later Red Hat Enterprise Linux 8.0 or later Red Hat Enterprise Linux 9.0 or later SUSE Linux Enterprise Server 12 SP4 or later SUSE Linux Enterprise Server 15 SP1 or later Ubuntu 16.04.6 LTS or later Ubuntu 18.04.3 LTS or later Ubuntu 20.04 LTS or later VMware ESXi 6.5 EP15 or later VMware ESXi 6.7 Update3 or later VMware ESXi 7.0 or later VMware ESXi 8.0 or later Windows Server 2016 (X2APIC/256T not supported) Windows Server 2019 |
| Management Solution | Aspeed® AST2500 Baseboard Management Controller GIGABYTE Management Console web interface |
| Dimensions | 438 x 43.5 x 660 mm |
| Form Factor | 1U |
| Weight | Net Weight: 13 Kg Gross Weight: 22 Kg |
| Power Supply | 1+1 1100W 80 PLUS Platinum redundant power supplies |
| Environment | Operating temperature: 10°C to 35°C Operating humidity: 8-80% (non-condensing) Non-operating temperature: -40°C to 60°C Non-operating humidity: 20%-95% (non-condensing) |
